WIKA · Temperature measurement · Family TC59

Tubeskin thermocouple assembly

Name: Tubeskin thermocouple assembly
Brand: WIKA

Tubeskin thermocouple assembly with contoured weld-pad for surface temperature measurement on tubes in industrial applications.

Range

0…1260 °C

Output

HART · FOUNDATION Fieldbus

Protection

IP65

CEEACRoHSREACHNACEIECExFMCSAATEX II 2 G Ex ia IICFM Class I Division 1FM Class I Division 2CSA Class I Division 1CSA Class I Division 2ATEXII 2 G Ex ia IICEACExNEPSIKCsPESO

Price

On request

Depends on configuration

Request a quote

+38 (067) 285-77-70·info@avigan.com.uaViberTelegram

Description

The WELD-PAD enables the measurement of temperatures on plain or contoured surfaces.

The WELD-PAD sensor hot end is a contoured weld-pad attached to a mineral-insulated cable (sheathed cable). It consists of a metal outer sheath, which contains the insulated internal leads, compressed within a high-density ceramic composition. The internal leads are made from thermo material. The material of the outer sheath can be selected to match the application. At one end of the sheathed cable, the internal leads are welded together to form an insulated (ungrounded) or non-insulated (grounded) measuring point.

At one end of the sheathed cable, the ends of the leads are connected and the sheathed cable is hermetically sealed using a sealing compound. The lead ends form the platform for the electrical connection. Cables, plug-in connectors or connector sockets can be connected to them.

further approvals see page 7

WELD-PAD

Tubeskin thermocouple assembly, model TC59-W

Special features

Application ranges from 0 ... 1,260 °C [32 ... 2,300 °F]
Flexible sheathed cable, mineral-insulated internal leads
High mechanical strength, shock-resistant
Explosion-protected versions

Identification

Model	TC59-W
Product family	TC59
Subcategory	Tubeskin thermocouple

Measuring range

Temperature ranges

+0…+1260 °C

Process conditions

Process connection	Compression fittingM20 x 1.5½ NPTSliding connection (piston/spring)1/2 NPT3x M20 x 1.5
Process temperature	+0…+1260 °C

Electrical characteristics

Output signal	HART · FOUNDATION Fieldbus · 4-20mA · PROFIBUS-PA
Power supply	Not specified
Electrical connection	Cable, plug-in connectors, terminal block

Materials

Probe material

Haynes HR 160, Pyrosil D, 1.4841 (310), 1.4749 (446), 1.4401 (316), Inconel 600, Hastelloy X, Stainless steel 1.4841 (310), Stainless steel 1.4401 (316), Stainless steel 1.4749 (446), 2.4816 (Inconel 600), 2.4665 (Hastelloy X), Ni-alloy 2.4816 (Inconel 600), 2.4665 (HastelloyX®), HaynesHR160®, PyrosilD®

Operating environment

Ambient temperature	−20…+85 °C
IP rating	IP65

Certifications and approvals

Certifications	CEEACRoHSREACHNACE
Explosion protection	IECExFMCSAATEX II 2 G Ex ia IICFM Class I Division 1FM Class I Division 2CSA Class I Division 1CSA Class I Division 2ATEXII 2 G Ex ia IICEACExNEPSIKCsPESO

Additional details

Sensor type	Type K/J/N/E
Sensor class	Class 1 and 2
Probe diameter	6 mm
Thermowell	No
Datasheet languages	EN, DE

Tables from datasheet

Type	Recommended max. operating temperature
IEC 60584-1	ASTM E230
K	1,200 °C (2,192 °F)	1,260 °C (2,300 °F)
J	750 °C (1,382 °F)	760 °C (1,400 °F)
N	1,200 °C (2,192 °F)	1,260 °C (2,300 °F)
E	900 °C (1,652 °F)	870 °C (1,598 °F)

Thermocouple	Class
Type	IEC 60584-1	ASTM E230
K	1 and 2	Standard, special
J	1 and 2	Standard, special
N	1 and 2	Standard, special
E	1 and 2	Standard, special

WELD-PAD material	Resistance in
	sulphurous ambient	maximum temperature
2.4665 (Hastelloy X ® )	Medium	1,150 °C (2,102 °F)
2.4816 (Inconel 600 ® )	Low	1,150 °C (2,102 °F)
Stainless steel 1.4841 (310)	Medium	1,150 °C (2,102 °F)
Stainless steel 1.4749 (446) 1)	High	1,150 °C (2,102 °F)
Haynes HR 160 ®	Very high	1,200 °C (2,192 °F)
Pyrosil D ®	High	1,250 °C (2,282 °F)
Stainless steel 1.4401 (316)	Medium	850 °C (1,562 °F)

Model	Material	Cable entry 1)	Ingress protection	Cap	Surface finish 2)
BSZ	Aluminium	M20 x 1.5	IP65	Hinged cover with cylinder head screw	Blue, painted
BSZ-K	Plastic	M20 x 1.5	IP65	Hinged cover with cylinder head screw	Plastic
BSZ-H	Aluminium	M20 x 1.5	IP65	Hinged cover with cylinder head screw	Blue, painted
BSS	Aluminium	M20 x 1.5	IP65	Hinged cover with clip	Blue, painted
1/4000 F	Aluminium	½NPT	IP66 3)	Screw cover	Blue, painted
1/4000 S	Stainless steel	½NPT	IP66 3)	Screw cover	Blank
5/6000 F	Aluminium	3 x M20 x 1.5	IP66 3)	Screw cover	Blue, painted
7/8000W	Aluminium	M20 x 1.5	IP66 3)	Screw cover	Blue, painted
7/8000 S	Stainless steel	½NPT	IP66 3)	Screw cover	Blank
DIH10/ BSZ-H	Aluminium	M20 x 1.5	IP65	Hinged cover with cylinder head screw and LED indicator DIH10	Blue, painted with indicator

View all (9)

Connection head	Transmitter model
T32	T53
BSZ/BSZ-K	○	○
BSZ-H	●	●
BSS	○	○
1/4000	○	○
5/6000	○	○
7/8000	○	○
DIH10	○	-

Model	Description	Explosion protection	Data sheet
T32	Digital transmitter, HART ® protocol	Optional	TE 32.04
T53	Digital transmitter FOUNDATION™ Fieldbus and PROFIBUS ® PA	Standard	TE 53.01
TIF50	Digital field temperature transmitter, HART ® protocol	Optional	TE 62.01

Thermocouple type	Positive leg	Negative leg
K	Green	White
J	Black	White
E	Violet	White
N	Pink	White

Thermocouple type	Positive leg	Negative leg
K	Yellow	Red
J	White	Red
E	Violet	Red
N	Orange	Red

Logo	Description	Country
	EU declaration of conformity ■ EMCdirective 1) EN 61326 emission (group 1, class B) and interference immunity (industrial application) ■ ATEX directive (option)	European Union
	IECEx (option) Hazardous areas	International
	FM (option) Hazardous areas	USA
	CSA (option) ■ Safety (e.g. electr. safety, overpressure, ...) ■ Hazardous areas	Canada
	EAC (option) ■ EMCdirective ■ Hazardous areas	Eurasian Economic Community
	INMETRO (option) ■ Metrology, measurement technology ■ Hazardous areas	Brazil
	NEPSI (option) Hazardous areas	China
	KCs - KOSHA (option) Hazardous areas	South Korea
-	6. Commissioning, operation PESO (option) Hazardous areas	India
