Pressure gauge snubber
Description
Snubbers are adjustable (modification of the flow cross-section) and can thus be adapted individually to the respective operating conditions. A readjustment during operation, if required, is possible at any time.
The pulsations and pressure surges in the medium, occurring e.g. in compressors, steam engines, hydraulic presses, tensile testing machines etc., are largely compensated by this device. Snubbers ensure a considerably prolonged service life of the pressure measuring instruments and improve the reading accuracy of pressure gauges.
Fig. left: Brass version
Fig. right: Stainless steel version
Special features
- Max. temperature 120 °C
- Nominal pressures up to 400 bar
| Model | 910.12 |
| Product family | 910 |
| Subcategory | Snubber |
| Pressure ranges | 0…400 bar |
| Accuracy standard | EN 837-1 |
| Process connection | G ½ BG ¼G ⅜M20 x 1.5¼ NPT½ NPT |
| Process temperature | −10…+120 °C |
| Case material | Brass, Steel, 1.4571, 1.4404 |
| Wetted parts material | 1.4404, Monel, 1.4571 |
| Sealing material | NBR, FPM |
| Ambient temperature | −10…+120 °C |
| Certifications | DIN 50049EN 10204 3.1 |
| Datasheet languages | EN |
| Material | PN | Temperature range | Order number | ||
|---|---|---|---|---|---|
| Body | Spindle | Sealing | bar | ||
| Brass | 1.4404 2) | NBR | 400 | -10 …+120 °C | 9090185 |
| Steel 1) | 1.4404 2) | NBR | 400 | -10 …+120 °C | 9090193 |
| 1.4571 2) | 1.4404 2) | FPM | 400 | -10 …+120 °C | 9091262 |
