WIKA · Pressure measurement · Family 33x.50
Test gauge, stainless steel
Test gauge, stainless steel, class 0.6, NS 160 [6"]
Range
-1…1600 bar
Accuracy
0.6
Protection
IP65
PEDCRN
Price
On request
Depends on configuration
Description
The model 33x.50 high-quality test gauge has been specifically designed for increased safety requirements during high-accuracy pressure measurements and is suited for calibration tasks. With an accuracy class of 0.6, the Bourdon tube pressure gauge is suitable for testing industrial type pressure gauges or for precision measurement in laboratories. For pressures ≤ 400 bar [6.000 psi] the instrument is also available with an accuracy class of 0.25.
The wear-resistant precision movement, the wetted parts and the case are made from high-grade stainless steel. WIKA manufactures and qualifies the pressure gauge in accordance with the standards EN 837-1 and ASME B40.100. This version has a blow-out device with blow-out plug on the back of the case. In the event of a failure, overpressure can escape there and the operator is protected at the front side.
For further approvals, see page 6
Special features
- Designed in compliance with the requirements of EN 837-1 and ASME B40.100
- Completely from stainless steel
- Knife edge pointer for optimal accuracy of reading
- Wear-resistant precision movement from stainless steel
- QR code on dial links to instrument-specific information
Configurator · Step by step
Build a 33X.50 for your task
The article number is assembled automatically. If unsure — ask an engineer; we'll match the line's parameters.
Step 1 of 2
Your configuration
- Case fillingwithout
- Unit of outer Scalebar
- Measuring rangegauge pressure range
- Scale range—
- 2nd Scale or Special Scalewithout
- Process connection—
- Connector locationlower mount
- Mounting flange/bracketwithout
- Windowlaminated safety glass
- Pointerknife-edge pointer, aluminium, black
- Dial Specialswithout
- Special design featureswithout
- Certificateswithout
AI suggestion by parameters
Finish your configuration
Select every option to submit the request.
Identification
| Model | 332.50 |
| Product family | 33x.50 |
| Subcategory | Test gauge |
Measuring range
| Pressure ranges | 0…0.6 bar · 0…1 bar · 0…1.6 bar · 0…2.5 bar · 0…4 bar · 0…6 bar · 0…7 bar · 0…10 bar · 0…14 bar · 0…16 bar · 0…20 bar · 0…25 bar · 0…30 bar · 0…40 bar · 0…60 kPa · 0…70 kPa · 0…100 kPa · 0…160 kPa · 0…200 kPa · 0…250 kPa · 0…300 kPa · 0…400 kPa · 0…600 kPa · 0…700 kPa · 0…1000 kPa · 0…1400 kPa · 0…1600 kPa · 0…2500 kPa · 0…10 psi · 0…15 psi · 0…30 psi · 0…60 psi · 0…100 psi · 0…150 psi · 0…160 psi · 0…200 psi · 0…250 psi · 0…300 psi · 0…400 psi · 0…600 psi · 0…0.06 MPa · 0…0.1 MPa · 0…0.16 MPa · 0…0.2 MPa · 0…0.25 MPa · 0…0.4 MPa · 0…0.6 MPa · 0…0.7 MPa · 0…1 MPa · 0…1.4 MPa · 0…1.6 MPa · 0…2 MPa · 0…2.5 MPa · 0…3 MPa · 0…0.6 kg/cm² · 0…1 kg/cm² · 0…1.6 kg/cm² · 0…2.5 kg/cm² · 0…4 kg/cm² · 0…6 kg/cm² · 0…7 kg/cm² · 0…10 kg/cm² · 0…14 kg/cm² · 0…16 kg/cm² · 0…20 kg/cm² · 0…25 kg/cm² · 0…30 kg/cm² · 0…40 kg/cm² · -0.6…0 bar · -1…0 bar · -1…0.6 bar · -1…1 bar · -1…1.5 bar · -1…2 bar · -1…3 bar · -1…5 bar · -60…0 kPa · -100…0 kPa · -100…60 kPa · -100…150 kPa · -100…200 kPa · -100…300 kPa · -100…400 kPa · -100…500 kPa · -0.06…0 MPa · -0.1…0 MPa · -0.1…0.06 MPa · -0.1…0.1 MPa · -0.1…0.15 MPa · -0.1…0.2 MPa · -0.1…0.3 MPa · -0.1…0.4 MPa · -15…0 inHg · -30…0 inHg · -30…15 inHg · -30…30 inHg · -30…60 inHg · 0…60 bar · 0…70 bar · 0…100 bar · 0…140 bar · 0…160 bar · 0…200 bar · 0…250 bar · 0…315 bar · 0…400 bar · 0…600 bar · 0…700 bar · 0…1000 bar · 0…1400 bar · 0…1600 bar · 0…3000 kPa · 0…4000 kPa · 0…6000 kPa · 0…7000 kPa · 0…10000 kPa · 0…14000 kPa · 0…16000 kPa · 0…20000 kPa · 0…25000 kPa · 0…31500 kPa · 0…40000 kPa · 0…60000 kPa · 0…70000 kPa · 0…100000 kPa · 0…800 psi · 0…1000 psi · 0…1500 psi · 0…2000 psi · 0…3000 psi · 0…4000 psi · 0…5000 psi · 0…6000 psi · 0…7500 psi · 0…10000 psi · 0…15000 psi · 0…20000 psi · 0…4 MPa · 0…6 MPa · 0…10 MPa · 0…14 MPa · 0…16 MPa · 0…20 MPa · 0…25 MPa · 0…31.5 MPa · 0…40 MPa · 0…60 MPa · 0…70 MPa · 0…100 MPa · 0…140 MPa · 0…160 MPa · 0…60 kg/cm² · 0…70 kg/cm² · 0…100 kg/cm² · 0…140 kg/cm² · 0…160 kg/cm² · 0…200 kg/cm² · 0…250 kg/cm² · 0…315 kg/cm² · 0…400 kg/cm² · 0…600 kg/cm² · 0…700 kg/cm² · 0…1000 kg/cm² · 0…1400 kg/cm² · 0…1600 kg/cm² |
Accuracy
| Accuracy class | 0.6 |
| Accuracy standard | EN 837-1 |
Process conditions
| Process connection | G ¼ BG ½ BM20 x 1.5R ¼R ½¼ NPT½ NPT |
| Process temperature | −20…+200 °C |
Materials
| Case material | Stainless steel |
| Wetted parts material | Stainless steel 1.4404 (316L), NiFe alloy |
Operating environment
| Ambient temperature | −40…+60 °C |
| IP rating | IP65 |
| Weight | 1.5 kg |
Certifications and approvals
| Certifications | PEDCRN |
Additional details
| Dial size | 160 mm |
Tables from datasheet
| bar | |
|---|---|
| 0 ... 0.6 | 0 ... 60 |
| 0 ... 1 | 0 ... 70 |
| 0 ... 1.6 | 0 ... 100 |
| 0 ... 2.5 | 0 ... 140 |
| 0 ... 4 | 0 ... 160 |
| 0 ... 6 | 0 ... 200 |
| 0 ... 7 | 0 ... 250 |
| 0 ... 10 | 0 ... 315 |
| 0 ... 14 | 0 ... 400 |
| 0 ... 16 | 0 ... 600 |
| 0 ... 20 | 0 ... 700 |
| 0 ... 25 | 0 ... 1,000 |
| 0 ... 30 | 0 ... 1,400 |
| 0 ... 40 | 0 ... 1,600 |
| kPa | |
|---|---|
| 0 ... 60 | 0 ... 3,000 |
| 0 ... 70 | 0 ... 4,000 |
| 0 ... 100 | 0 ... 6,000 |
| 0 ... 160 | 0 ... 7,000 |
| 0 ... 200 | 0 ... 10,000 |
| 0 ... 250 | 0 ... 14,000 |
| 0 ... 300 | 0 ... 16,000 |
| 0 ... 400 | 0 ... 20,000 |
| 0 ... 600 | 0 ... 25,000 |
| 0 ... 700 | 0 ... 31,500 |
| 0 ... 1,000 | 0 ... 40,000 |
| 0 ... 1,400 | 0 ... 60,000 |
| 0 ... 1,600 | 0 ... 70,000 |
| 0 ... 2,500 | 0 ... 100,000 |
| psi | |
|---|---|
| 0 ... 10 | 0 ... 800 |
| 0 ... 15 | 0 ... 1,000 |
| 0 ... 30 | 0 ... 1,500 |
| 0 ... 60 | 0 ... 2,000 |
| 0 ... 100 | 0 ... 3,000 |
| 0 ... 150 | 0 ... 4,000 |
| 0 ... 160 | 0 ... 5,000 |
| 0 ... 200 | 0 ... 6,000 |
| 0 ... 250 | 0 ... 7,500 |
| 0 ... 300 | 0 ... 10,000 |
| 0 ... 400 | 0 ... 15,000 |
| 0 ... 600 | 0 ... 20,000 |
| MPa | |
|---|---|
| 0 ... 0.06 | 0 ... 4 |
| 0 ... 0.1 | 0 ... 6 |
| 0 ... 0.16 | 0 ... 10 |
| 0 ... 0.20 | 0 ... 14 |
| 0 ... 0.25 | 0 ... 16 |
| 0 ... 0.4 | 0 ... 20 |
| 0 ... 0.6 | 0 ... 25 |
| 0 ... 0.7 | 0 ... 31.5 |
| 0 ... 1 | 0 ... 40 |
| 0 ... 1.4 | 0 ... 60 |
| 0 ... 1.6 | 0 ... 70 |
| 0 ... 2 | 0 ... 100 |
| 0 ... 2.5 | 0 ... 140 |
| 0 ... 3 | 0 ... 160 |
View all (18)
| kg/cm 2 | |
|---|---|
| 0 ... 0.6 | 0 ... 60 |
| 0 ... 1 | 0 ... 70 |
| 0 ... 1.6 | 0 ... 100 |
| 0 ... 2.5 | 0 ... 140 |
| 0 ... 4 | 0 ... 160 |
| 0 ... 6 | 0 ... 200 |
| 0 ... 7 | 0 ... 250 |
| 0 ... 10 | 0 ... 315 |
| 0 ... 14 | 0 ... 400 |
| 0 ... 16 | 0 ... 600 |
| 0 ... 20 | 0 ... 700 |
| 0 ... 25 | 0 ... 1,000 |
| 0 ... 30 | 0 ... 1,400 |
| 0 ... 40 | 0 ... 1,600 |
| bar | |
|---|---|
| -0.6 ... 0 | -1 ...+7 |
| -1 ... 0 | -1 ...+9 |
| -1 ... +0.6 | -1 ...+10 |
| -1 ...+1 | -1 ...+15 |
| -1 ... +1.5 | -1 ...+24 |
| -1 ...+2 | -1 ...+15 |
| -1 ...+3 | -1 ...+30 |
| -1 ...+5 | - |
kPa
| -60 ... 0 | -100 ...+700 |
|---|---|
| -100 ... 0 | -100 ...+900 |
| -100 ...+60 | -100 ... +1,000 |
| -100 ...+150 | -100 ... +1,500 |
| -100 ...+200 | -100 ... +1,500 |
| -100 ...+300 | -100 ... +2,400 |
| -100 ...+400 | -100 ... +3,000 |
| -100 ...+500 | - |
psi
| -15 inHg ... 0 | -30 inHg ...+100 |
|---|---|
| -30 inHg ... 0 | -30 inHg ...+160 |
| -30 inHg ...+15 | -30 inHg ...+200 |
| -30 inHg ...+30 | -30 inHg ...+300 |
| -30 inHg ...+60 | - |
Further details on: scale ranges
| Special scale ranges | Other scale ranges on request |
|---|---|
| Unit | ■ bar ■ psi ■ kg/cm² ■ kPa ■ MPa |
| Increased overload safety | ■ Without ■ 1.3 times |
| The possibility of selection depends on the scale range | |
| Vacuum resistance | Vacuum-resistant to -1 bar [-30 inHg] |
| Dial | |
| Reading aid | ■ Without ■ Mirror band scale |
| Scale colour | Black |
| Material | Aluminium |
| Special scale | Other scales or customer-specific dials, e.g. with red mark, circular arcs or circular sectors, on request |
kg/cm 2
| -0.6 ... 0 | -1 ...+7 |
|---|---|
| -1 ... 0 | -1 ...+9 |
| -1 ... +0.6 | -1 ...+10 |
| -1 ...+1 | -1 ...+15 |
| -1 ... +1.5 | -1 ...+24 |
| -1 ...+2 | -1 ...+15 |
| -1 ...+3 | -1 ...+30 |
| -1 ...+5 | - |
MPa
| -0.06 ... 0 | -0.1 ... +0.5 |
|---|---|
| -0.1 ... 0 | -0.1 ... +0.7 |
| -0.1 ... +0.06 | -0.1 ... +0.9 |
| -0.1 ... +0.1 | -0.1 ...+1 |
| -0.1 ... +0.15 | -0.1 ... +1.5 |
| -0.1 ... +0.2 | -0.1 ... +2.4 |
| -0.1 ... +0.3 | -0.1 ...+3 |
| -0.1 ... +0.4 | - |
| Logo | Description | Country |
|---|---|---|
| EU declaration of conformity | European Union | |
| - | CRN | Canada |
| Logo | Description | Country |
|---|---|---|
| PAC Kazakhstan Metrology, measurement technology | Kazakhstan | |
| - | MChS Permission for commissioning | Kazakhstan |
| - | PAC Ukraine Metrology, measurement technology | Ukraine |
| PAC Uzbekistan Metrology, measurement technology | Uzbekistan | |
| - | PAC China Metrology, measurement technology | China |
| Logo | Description |
|---|---|
| - | Pressure Equipment Directive (PED) for maximum allowable pressure PS ≤ 200 bar |
| - | Suitability of wetted materials for drinking water in accordance with the European 4MS initiative |
Certificates
| Certificates | ■ 2.2 test report per EN 10204 (e.g. state-of-the-art manufacturing, indication accuracy) ■ 3.1 inspection certificate per EN 10204 (e.g. material proof for wetted metal parts, indication accuracy) ■ PCA calibration certificate (traceable and accredited in accordance with ISO/IEC 17025) ■ Calibration certificate by a national accreditation body (traceable and accredited in accordance with ISO/IEC 17025) on request |
|---|---|
| Recommended calibration interval | 1 year (dependent on conditions of use) |
| G | Dimensions in mm[in] | |||||
|---|---|---|---|---|---|---|
| h ±1 [0.04] | b1 ±1 [0.04] | b ±0.5 [0.02] | a | D | S3 | |
| G ¼ B | 111 [4.37] Abmessungen in mm [inch] | 75.9 [2.99] | 51.4 [2.02] | 15.5 [0.61] | 161 [6.34] | 20 [0.79] |
| G½B | 118 [4.65] Dimensions in mm [inch] ± 0,5 b1 ± 1 | 82.9 [3.26] | 51.4 [2.02] | 15.5 [0.61] | 161 [6.34] | 20 [0.79] |
| M20 1.5 ⌀ D b | 118 [4.65] ± 0.02] b1 [ ± 0.04] | 82.9 [3.26] S3 | 51.4 [2.02] | 15.5 [0.61] | 161 [6.34] | 20 [0.79] |
| ¼ NPT, R ¼ | 111 [4.37] 82,9 [3.26] | 75.9 [2.99] | 51.4 [2.02] | 15.5 [0.61] | 161 [6.34] | 20 [0.79] |
| ½NPT,R½ | 117 [4.61] 75,9 | 81.9 [3.22] | 51.4 [2.02] | 15.5 [0.61] | 161 [6.34] | 20 [0.79] |
Weight in kg [lb] 75,9 [2.99]
| Model 332.50 | Model 333.50 |
|---|---|
| 1.50 [4.019] | 2.70 [7.234] |
| Model | Description | |
|---|---|---|
| 910.17 | Seals → See data sheet AC 09.08 | |
| 910.15 | Syphons → See data sheet AC 09.06 | |
| 910.13 | Overpressure protector → See data sheet AC 09.04 | |
| IV1 | Needle valve and multiport needle valve → See data sheet AC 09.22 | |
| IV2 | Block-and-bleed valve → See data sheet AC 09.19 | |
| IVM | Monoflange, process and instrument version → See data sheet AC 09.17 | |
| BV | Ball valve, process and instrument version → See data sheet AC 09.28 | |
| IBF2, IBF3 | Monoblock with flange connection → See data sheet AC 09.25 |
Industry
Machinery
High-accuracy pressure measurement · Testing of industrial type pressure gauges · With liquid-filled case (model 333.50) for applications with high dynamic pressure loads or vibrations
Couldn't find the answer in the documentation? An engineer will reply within a business day.
Ask an engineer →All variants · Article table
104 standard articles of family 33x.50
If you know the code — pick directly. If not — use the configurator in mode “01”.
Stock:
SKUConfigurationPriceStockAction
332.50-F-BG260Z-GD-UZHZGZZZ-ZZZZCase filling: 2 · Unit of outer Scale: B · Measuring range: BG+ 10 moreOn requestOn orderRequest →
332.50-F-BG260Z-ND-UZHZGZZZ-ZZZZCase filling: 2 · Unit of outer Scale: B · Measuring range: BG+ 10 moreOn requestOn orderRequest →
332.50-F-BG260Z-GB-UZHZGZZZ-ZZZZCase filling: 2 · Unit of outer Scale: B · Measuring range: BG+ 10 moreOn requestOn orderRequest →
332.50-F-BG260Z-GC-UZHZGZZZ-ZZZZCase filling: 2 · Unit of outer Scale: B · Measuring range: BG+ 10 moreOn requestOn orderRequest →
332.50-F-BG260Z-NB-UZHZGZZZ-ZZZZCase filling: 2 · Unit of outer Scale: B · Measuring range: BG+ 10 moreOn requestOn orderRequest →
332.50-F-BG260Z-MI-UZHZGZZZ-ZZZZCase filling: 2 · Unit of outer Scale: B · Measuring range: BG+ 10 moreOn requestOn orderRequest →
332.50-F-BG316Z-GD-UZHZGZZZ-ZZZZCase filling: 2 · Unit of outer Scale: B · Measuring range: BG+ 10 moreOn requestOn orderRequest →
332.50-F-BG316Z-ND-UZHZGZZZ-ZZZZCase filling: 2 · Unit of outer Scale: B · Measuring range: BG+ 10 moreOn requestOn orderRequest →
332.50-F-BG316Z-GB-UZHZGZZZ-ZZZZCase filling: 2 · Unit of outer Scale: B · Measuring range: BG+ 10 moreOn requestOn orderRequest →
332.50-F-BG316Z-GC-UZHZGZZZ-ZZZZCase filling: 2 · Unit of outer Scale: B · Measuring range: BG+ 10 moreOn requestOn orderRequest →
332.50-F-BG316Z-NB-UZHZGZZZ-ZZZZCase filling: 2 · Unit of outer Scale: B · Measuring range: BG+ 10 moreOn requestOn orderRequest →
332.50-F-BG316Z-MI-UZHZGZZZ-ZZZZCase filling: 2 · Unit of outer Scale: B · Measuring range: BG+ 10 moreOn requestOn orderRequest →
332.50-F-BG325Z-GD-UZHZGZZZ-ZZZZCase filling: 2 · Unit of outer Scale: B · Measuring range: BG+ 10 moreOn requestOn orderRequest →
332.50-F-BG325Z-ND-UZHZGZZZ-ZZZZCase filling: 2 · Unit of outer Scale: B · Measuring range: BG+ 10 moreOn requestOn orderRequest →
332.50-F-BG325Z-GB-UZHZGZZZ-ZZZZCase filling: 2 · Unit of outer Scale: B · Measuring range: BG+ 10 moreOn requestOn orderRequest →
332.50-F-BG325Z-GC-UZHZGZZZ-ZZZZCase filling: 2 · Unit of outer Scale: B · Measuring range: BG+ 10 moreOn requestOn orderRequest →
332.50-F-BG325Z-NB-UZHZGZZZ-ZZZZCase filling: 2 · Unit of outer Scale: B · Measuring range: BG+ 10 moreOn requestOn orderRequest →
332.50-F-BG325Z-MI-UZHZGZZZ-ZZZZCase filling: 2 · Unit of outer Scale: B · Measuring range: BG+ 10 moreOn requestOn orderRequest →
332.50-F-BG340Z-GD-UZHZGZZZ-ZZZZCase filling: 2 · Unit of outer Scale: B · Measuring range: BG+ 10 moreOn requestOn orderRequest →
332.50-F-BG340Z-ND-UZHZGZZZ-ZZZZCase filling: 2 · Unit of outer Scale: B · Measuring range: BG+ 10 moreOn requestOn orderRequest →
332.50-F-BG340Z-GB-UZHZGZZZ-ZZZZCase filling: 2 · Unit of outer Scale: B · Measuring range: BG+ 10 moreOn requestOn orderRequest →
332.50-F-BG340Z-GC-UZHZGZZZ-ZZZZCase filling: 2 · Unit of outer Scale: B · Measuring range: BG+ 10 moreOn requestOn orderRequest →
332.50-F-BG340Z-NB-UZHZGZZZ-ZZZZCase filling: 2 · Unit of outer Scale: B · Measuring range: BG+ 10 moreOn requestOn orderRequest →
332.50-F-BG340Z-MI-UZHZGZZZ-ZZZZCase filling: 2 · Unit of outer Scale: B · Measuring range: BG+ 10 moreOn requestOn orderRequest →
332.50-F-BG360Z-GD-UZHZGZZZ-ZZZZCase filling: 2 · Unit of outer Scale: B · Measuring range: BG+ 10 moreOn requestOn orderRequest →
332.50-F-BG360Z-ND-UZHZGZZZ-ZZZZCase filling: 2 · Unit of outer Scale: B · Measuring range: BG+ 10 moreOn requestOn orderRequest →
332.50-F-BG360Z-GB-UZHZGZZZ-ZZZZCase filling: 2 · Unit of outer Scale: B · Measuring range: BG+ 10 moreOn requestOn orderRequest →
332.50-F-BG360Z-GC-UZHZGZZZ-ZZZZCase filling: 2 · Unit of outer Scale: B · Measuring range: BG+ 10 moreOn requestOn orderRequest →
332.50-F-BG360Z-NB-UZHZGZZZ-ZZZZCase filling: 2 · Unit of outer Scale: B · Measuring range: BG+ 10 moreOn requestOn orderRequest →
332.50-F-BG360Z-MI-UZHZGZZZ-ZZZZCase filling: 2 · Unit of outer Scale: B · Measuring range: BG+ 10 moreOn requestOn orderRequest →
332.50-F-BG410Z-GD-UZHZGZZZ-ZZZZCase filling: 2 · Unit of outer Scale: B · Measuring range: BG+ 10 moreOn requestOn orderRequest →
332.50-F-BG410Z-ND-UZHZGZZZ-ZZZZCase filling: 2 · Unit of outer Scale: B · Measuring range: BG+ 10 moreOn requestOn orderRequest →
332.50-F-BG410Z-GB-UZHZGZZZ-ZZZZCase filling: 2 · Unit of outer Scale: B · Measuring range: BG+ 10 moreOn requestOn orderRequest →
332.50-F-BG410Z-GC-UZHZGZZZ-ZZZZCase filling: 2 · Unit of outer Scale: B · Measuring range: BG+ 10 moreOn requestOn orderRequest →
332.50-F-BG410Z-NB-UZHZGZZZ-ZZZZCase filling: 2 · Unit of outer Scale: B · Measuring range: BG+ 10 moreOn requestOn orderRequest →
332.50-F-BG410Z-MI-UZHZGZZZ-ZZZZCase filling: 2 · Unit of outer Scale: B · Measuring range: BG+ 10 moreOn requestOn orderRequest →
332.50-F-BG416Z-GD-UZHZGZZZ-ZZZZCase filling: 2 · Unit of outer Scale: B · Measuring range: BG+ 10 moreOn requestOn orderRequest →
332.50-F-BG416Z-ND-UZHZGZZZ-ZZZZCase filling: 2 · Unit of outer Scale: B · Measuring range: BG+ 10 moreOn requestOn orderRequest →
332.50-F-BG416Z-GB-UZHZGZZZ-ZZZZCase filling: 2 · Unit of outer Scale: B · Measuring range: BG+ 10 moreOn requestOn orderRequest →
332.50-F-BG416Z-GC-UZHZGZZZ-ZZZZCase filling: 2 · Unit of outer Scale: B · Measuring range: BG+ 10 moreOn requestOn orderRequest →
332.50-F-BG416Z-NB-UZHZGZZZ-ZZZZCase filling: 2 · Unit of outer Scale: B · Measuring range: BG+ 10 moreOn requestOn orderRequest →
332.50-F-BG416Z-MI-UZHZGZZZ-ZZZZCase filling: 2 · Unit of outer Scale: B · Measuring range: BG+ 10 moreOn requestOn orderRequest →
332.50-F-BG425Z-GD-UZHZGZZZ-ZZZZCase filling: 2 · Unit of outer Scale: B · Measuring range: BG+ 10 moreOn requestOn orderRequest →
332.50-F-BG425Z-ND-UZHZGZZZ-ZZZZCase filling: 2 · Unit of outer Scale: B · Measuring range: BG+ 10 moreOn requestOn orderRequest →
332.50-F-BG425Z-GB-UZHZGZZZ-ZZZZCase filling: 2 · Unit of outer Scale: B · Measuring range: BG+ 10 moreOn requestOn orderRequest →
332.50-F-BG425Z-GC-UZHZGZZZ-ZZZZCase filling: 2 · Unit of outer Scale: B · Measuring range: BG+ 10 moreOn requestOn orderRequest →
332.50-F-BG425Z-NB-UZHZGZZZ-ZZZZCase filling: 2 · Unit of outer Scale: B · Measuring range: BG+ 10 moreOn requestOn orderRequest →
332.50-F-BG425Z-MI-UZHZGZZZ-ZZZZCase filling: 2 · Unit of outer Scale: B · Measuring range: BG+ 10 moreOn requestOn orderRequest →
332.50-F-BG440Z-GD-UZHZGZZZ-ZZZZCase filling: 2 · Unit of outer Scale: B · Measuring range: BG+ 10 moreOn requestOn orderRequest →
332.50-F-BG440Z-ND-UZHZGZZZ-ZZZZCase filling: 2 · Unit of outer Scale: B · Measuring range: BG+ 10 moreOn requestOn orderRequest →
332.50-F-BG440Z-GB-UZHZGZZZ-ZZZZCase filling: 2 · Unit of outer Scale: B · Measuring range: BG+ 10 moreOn requestOn orderRequest →
332.50-F-BG440Z-GC-UZHZGZZZ-ZZZZCase filling: 2 · Unit of outer Scale: B · Measuring range: BG+ 10 moreOn requestOn orderRequest →
332.50-F-BG440Z-NB-UZHZGZZZ-ZZZZCase filling: 2 · Unit of outer Scale: B · Measuring range: BG+ 10 moreOn requestOn orderRequest →
332.50-F-BG440Z-MI-UZHZGZZZ-ZZZZCase filling: 2 · Unit of outer Scale: B · Measuring range: BG+ 10 moreOn requestOn orderRequest →
332.50-F-BG460Z-GD-UZHZGZZZ-ZZZZCase filling: 2 · Unit of outer Scale: B · Measuring range: BG+ 10 moreOn requestOn orderRequest →
332.50-F-BG460Z-ND-UZHZGZZZ-ZZZZCase filling: 2 · Unit of outer Scale: B · Measuring range: BG+ 10 moreOn requestOn orderRequest →
332.50-F-BG460Z-GB-UZHZGZZZ-ZZZZCase filling: 2 · Unit of outer Scale: B · Measuring range: BG+ 10 moreOn requestOn orderRequest →
332.50-F-BG460Z-GC-UZHZGZZZ-ZZZZCase filling: 2 · Unit of outer Scale: B · Measuring range: BG+ 10 moreOn requestOn orderRequest →
332.50-F-BG460Z-NB-UZHZGZZZ-ZZZZCase filling: 2 · Unit of outer Scale: B · Measuring range: BG+ 10 moreOn requestOn orderRequest →
332.50-F-BG460Z-MI-UZHZGZZZ-ZZZZCase filling: 2 · Unit of outer Scale: B · Measuring range: BG+ 10 moreOn requestOn orderRequest →
332.50-F-BG510Z-GD-UZHZGZZZ-ZZZZCase filling: 2 · Unit of outer Scale: B · Measuring range: BG+ 10 moreOn requestOn orderRequest →
332.50-F-BG510Z-ND-UZHZGZZZ-ZZZZCase filling: 2 · Unit of outer Scale: B · Measuring range: BG+ 10 moreOn requestOn orderRequest →
332.50-F-BG510Z-GB-UZHZGZZZ-ZZZZCase filling: 2 · Unit of outer Scale: B · Measuring range: BG+ 10 moreOn requestOn orderRequest →
332.50-F-BG510Z-GC-UZHZGZZZ-ZZZZCase filling: 2 · Unit of outer Scale: B · Measuring range: BG+ 10 moreOn requestOn orderRequest →
332.50-F-BG510Z-NB-UZHZGZZZ-ZZZZCase filling: 2 · Unit of outer Scale: B · Measuring range: BG+ 10 moreOn requestOn orderRequest →
332.50-F-BG510Z-MI-UZHZGZZZ-ZZZZCase filling: 2 · Unit of outer Scale: B · Measuring range: BG+ 10 moreOn requestOn orderRequest →
332.50-F-BG514Z-GD-UZHZGZZZ-ZZZZCase filling: 2 · Unit of outer Scale: B · Measuring range: BG+ 10 moreOn requestOn orderRequest →
332.50-F-BG514Z-ND-UZHZGZZZ-ZZZZCase filling: 2 · Unit of outer Scale: B · Measuring range: BG+ 10 moreOn requestOn orderRequest →
332.50-F-BG514Z-GB-UZHZGZZZ-ZZZZCase filling: 2 · Unit of outer Scale: B · Measuring range: BG+ 10 moreOn requestOn orderRequest →
332.50-F-BG514Z-GC-UZHZGZZZ-ZZZZCase filling: 2 · Unit of outer Scale: B · Measuring range: BG+ 10 moreOn requestOn orderRequest →
332.50-F-BG514Z-NB-UZHZGZZZ-ZZZZCase filling: 2 · Unit of outer Scale: B · Measuring range: BG+ 10 moreOn requestOn orderRequest →
332.50-F-BG514Z-MI-UZHZGZZZ-ZZZZCase filling: 2 · Unit of outer Scale: B · Measuring range: BG+ 10 moreOn requestOn orderRequest →
332.50-F-BG516Z-GD-UZHZGZZZ-ZZZZCase filling: 2 · Unit of outer Scale: B · Measuring range: BG+ 10 moreOn requestOn orderRequest →
332.50-F-BG516Z-ND-UZHZGZZZ-ZZZZCase filling: 2 · Unit of outer Scale: B · Measuring range: BG+ 10 moreOn requestOn orderRequest →
332.50-F-BG516Z-GB-UZHZGZZZ-ZZZZCase filling: 2 · Unit of outer Scale: B · Measuring range: BG+ 10 moreOn requestOn orderRequest →
332.50-F-BG516Z-GC-UZHZGZZZ-ZZZZCase filling: 2 · Unit of outer Scale: B · Measuring range: BG+ 10 moreOn requestOn orderRequest →
332.50-F-BG516Z-NB-UZHZGZZZ-ZZZZCase filling: 2 · Unit of outer Scale: B · Measuring range: BG+ 10 moreOn requestOn orderRequest →
332.50-F-BG516Z-MI-UZHZGZZZ-ZZZZCase filling: 2 · Unit of outer Scale: B · Measuring range: BG+ 10 moreOn requestOn orderRequest →
332.50-F-BG525Z-GD-UZHZGZZZ-ZZZZCase filling: 2 · Unit of outer Scale: B · Measuring range: BG+ 10 moreOn requestOn orderRequest →
332.50-F-BG525Z-ND-UZHZGZZZ-ZZZZCase filling: 2 · Unit of outer Scale: B · Measuring range: BG+ 10 moreOn requestOn orderRequest →
332.50-F-BG525Z-GB-UZHZGZZZ-ZZZZCase filling: 2 · Unit of outer Scale: B · Measuring range: BG+ 10 moreOn requestOn orderRequest →
332.50-F-BG525Z-GC-UZHZGZZZ-ZZZZCase filling: 2 · Unit of outer Scale: B · Measuring range: BG+ 10 moreOn requestOn orderRequest →
332.50-F-BG525Z-NB-UZHZGZZZ-ZZZZCase filling: 2 · Unit of outer Scale: B · Measuring range: BG+ 10 moreOn requestOn orderRequest →
332.50-F-BG525Z-MI-UZHZGZZZ-ZZZZCase filling: 2 · Unit of outer Scale: B · Measuring range: BG+ 10 moreOn requestOn orderRequest →
332.50-F-BG540Z-GD-UZHZGZZZ-ZZZZCase filling: 2 · Unit of outer Scale: B · Measuring range: BG+ 10 moreOn requestOn orderRequest →
332.50-F-BG540Z-ND-UZHZGZZZ-ZZZZCase filling: 2 · Unit of outer Scale: B · Measuring range: BG+ 10 moreOn requestOn orderRequest →
332.50-F-BG540Z-GB-UZHZGZZZ-ZZZZCase filling: 2 · Unit of outer Scale: B · Measuring range: BG+ 10 moreOn requestOn orderRequest →
332.50-F-BG540Z-GC-UZHZGZZZ-ZZZZCase filling: 2 · Unit of outer Scale: B · Measuring range: BG+ 10 moreOn requestOn orderRequest →
332.50-F-BG540Z-NB-UZHZGZZZ-ZZZZCase filling: 2 · Unit of outer Scale: B · Measuring range: BG+ 10 moreOn requestOn orderRequest →
332.50-F-BG540Z-MI-UZHZGZZZ-ZZZZCase filling: 2 · Unit of outer Scale: B · Measuring range: BG+ 10 moreOn requestOn orderRequest →
332.50-F-BG560Z-GD-UZHZGZZZ-ZZZZCase filling: 2 · Unit of outer Scale: B · Measuring range: BG+ 10 moreOn requestOn orderRequest →
332.50-F-BG560Z-ND-UZHZGZZZ-ZZZZCase filling: 2 · Unit of outer Scale: B · Measuring range: BG+ 10 moreOn requestOn orderRequest →
332.50-F-BG560Z-GB-UZHZGZZZ-ZZZZCase filling: 2 · Unit of outer Scale: B · Measuring range: BG+ 10 moreOn requestOn orderRequest →
332.50-F-BG560Z-GC-UZHZGZZZ-ZZZZCase filling: 2 · Unit of outer Scale: B · Measuring range: BG+ 10 moreOn requestOn orderRequest →
332.50-F-BG560Z-NB-UZHZGZZZ-ZZZZCase filling: 2 · Unit of outer Scale: B · Measuring range: BG+ 10 moreOn requestOn orderRequest →
332.50-F-BG560Z-MI-UZHZGZZZ-ZZZZCase filling: 2 · Unit of outer Scale: B · Measuring range: BG+ 10 moreOn requestOn orderRequest →
332.50-F-BG610Z-GD-UZHZGZZZ-ZZZZCase filling: 2 · Unit of outer Scale: B · Measuring range: BG+ 10 moreOn requestOn orderRequest →
332.50-F-BG610Z-ND-UZHZGZZZ-ZZZZCase filling: 2 · Unit of outer Scale: B · Measuring range: BG+ 10 moreOn requestOn orderRequest →
332.50-F-BG610Z-GB-UZHZGZZZ-ZZZZCase filling: 2 · Unit of outer Scale: B · Measuring range: BG+ 10 moreOn requestOn orderRequest →
332.50-F-BG610Z-GC-UZHZGZZZ-ZZZZCase filling: 2 · Unit of outer Scale: B · Measuring range: BG+ 10 moreOn requestOn orderRequest →
332.50-F-BG610Z-NB-UZHZGZZZ-ZZZZCase filling: 2 · Unit of outer Scale: B · Measuring range: BG+ 10 moreOn requestOn orderRequest →
332.50-F-BG610Z-MI-UZHZGZZZ-ZZZZCase filling: 2 · Unit of outer Scale: B · Measuring range: BG+ 10 moreOn requestOn orderRequest →
332.50-F-BG616Z-GD-UZHZGZZZ-ZZZZCase filling: 2 · Unit of outer Scale: B · Measuring range: BG+ 10 moreOn requestOn orderRequest →
332.50-F-BG616Z-ND-UZHZGZZZ-ZZZZCase filling: 2 · Unit of outer Scale: B · Measuring range: BG+ 10 moreOn requestOn orderRequest →
Showing 104 of 104. Price on request — an engineer will quote your configuration.
