WIKA · Pressure measurement · Family 130
Bourdon tube pressure gauge, stainless steel
For HP (high purity) applications
Range
0…700 bar
Accuracy
Grade B per ASME B40.1
Protection
IP54
Price
On request
Depends on configuration
Special features
- 316L wetted parts
- Electro-polished SS case & face-seal connection
- Positive and compound pressure ranges to 10,000 psi
Identification
| Model | 130.15 |
| Product family | 130 |
| Subcategory | Mechanical pressure gauge |
Measuring range
| Pressure ranges | 0…1 bar · 0…700 bar · 0…15 psi · 0…10000 psi |
Accuracy
| Accuracy class | Grade B per ASME B40.1 |
| Accuracy standard | ASME B40.1 |
Process conditions
| Process connection | ¼ NPT |
| Process temperature | −40…+100 °C |
Materials
| Case material | Stainless steel 316L, Stainless steel |
| Wetted parts material | Stainless steel 316L |
Operating environment
| Ambient temperature | −40…+60 °C |
| IP rating | IP54 |
Additional details
| Dial size | 50 mm |
| Datasheet languages | EN, DE |
Industry
Chemistry / Pharma
Semiconductor and electronic industry, medical industry, gene technology, biotechnology and pharmaceutical industries.
Industry
Machinery
Suitable for corrosive environments and gaseous or liquid media that will not obstruct the pressure system
