Min. flow rate

2 l/min (0.5 USgpm)

Max. flow rate

40 l/min (11 USgpm)

Flow rate ratio (q_min : q_max)

1 : 20

Minimum delivery quantity e

3.0 l (0.79 USg)

Error limits

2% of the actual value

Nominal pressure

PN 40 ((MWP 580 psi)

Max. permissible pressure loss

7 bar (102 psi); bei q_max and 100 mPa·s (cp) the pressure loss is approx. 1 bar (14.5 psi)

Max. permissible liquid temperature

60 °C (140 °F)

Permissible ambient temperature

10 ... 60 °C (50 ... 140 °F)

Hose connection for liquid

• Input

Female thread G½ DIN ISO 228/1

• Output

Female thread G¾ DIN ISO 228/1

Double-pointer dial

Values per revolution Large/small pointer

 1 l/20 l

Totalizer

• End value

9999 l

• Minimum flow rate

1 l

Certificate and approvals

Classification according to pressure equipment directive (DRGL 97/23/EC)

For liquids of fluid gas group 1; complies with requirements of article 3, paragraph 3 (sound engineering practice SEP)
